Description
Parameter | Specification |
---|---|
Body Material | Aluminum alloy |
Color | Black |
Unfolding Size | 1800mm * 650mm * 1150mm |
Hub Form | Wire spoked wheels |
Wheel Size | 26 inches |
Package Size | 1600mm * 300mm * 820mm |
Gross/Net Weight | 38kgs / 31.5kgs (83.78lbs / 69.45lbs) |
Maximum Load | 120kg (264.55 lbs) |
Maximum Speed | 25Km/h (15 mph) |
Mileage | 55KM-80KM (varies by load, temperature, terrain) |
Maximum Climbing Angle | 25 degrees |
Operating Temperature | -10~45°C |
Waterproof Level | IP54 |
Battery Type | 18650 lithium-ion power battery |
Battery Capacity | 15Ah |
Battery Rated Voltage | 48V |
Motor Rated Power | 250W |
Motor Form | Assist mode |
Motor Type | 26-inch / 48V / high-speed brushless motor with gear |
Motor Rated No-Load Speed | 350r/min |
Charger Output | 54.6V / 2.0A |
Charger Input | 100~240V 50/60Hz 3.0A |
Undervoltage Protection | 39V+1V |
Overcurrent Protection | 20A+1A |
Charging Time | 6-7 hours |
Instrument Display | Multifunctional LCD screen |
Front Lighting | Yes |
Braking Method | Front disc brake + Rear disc brake |
Tire Specifications | 26 x 4.0 Pneumatic tires |
Air Valve | 26×4.0 (Inner tube valve: AV) |
Front Fork | Shock fork |
Gear System | 7-Speed transmission |
