Description
Parameter | Details |
---|---|
Frame Material | Carbon Steel |
Color | Black |
Unfolded Size | 1680mm x 690mm x 950mm |
Hub Type | Integrated Wheel |
Wheel Size | 20 Inches |
Package Size | 1470mm x 280mm x 870mm |
Gross / Net Weight | 47.8kg / 40.6kg (105.38lb / 89.51lb) |
Max Load Capacity | 120kg (264.55lb) |
Max Speed | 25km/h (15.53mph) |
Mileage | 80km-150km (influenced by load, temperature, road conditions, and riding mode) |
Max Climbing Angle | 25 Degrees |
Operating Temperature | -10°C to 45°C |
Waterproof Level | IP54 |
Battery Type | 18650 Lithium-Ion Power Battery |
Battery Capacity | 13Ah*2 (624Wh) |
Battery Rated Voltage | 48V |
Motor Rated Power | 500W (0.25kW) |
Motor Type | Integrated Brushless Hub Motor |
Motor No-Load Speed | 380±10r/min |
Charger Output | 54.6V 2.0A |
Charger Input | 100~240V 50/60Hz 3.0A |
Undervoltage Protection | 39V |
Overcurrent Protection | 20A |
Charging Time | 6-7 Hours per Battery (supports dual charging with 2 chargers) |
Display | Multifunctional LCD Screen |
Front Light | Yes |
Brake System | Front & Rear Disc Brakes |
Tire Type | Pneumatic Tires |
Tire Specifications | 20 x 4.0 |
Valve Type | AV |
Front Fork | Shock Absorbing Fork |
Gears | 7-Speed Transmission |
